Technical Characteristics

Brand HI-LUX
Product Type Plough Lamp
Voltage 12V 35W
Source Bulb BTO
Amperage 2.4 Amp
Consumption 35W
Color White
Housing CRCA, powder coated PP glossy black
Connector Terminal 1-way male connector
Mounting Mounting bracket with 112mm CD Ø9
Lens Material Glass
Shape Round
Width 150mm
Reflector CRCA, Al. Metalized
Weight 870grm
IP protection IP55
Operation Temperatures -40°C to +85°C
Salt Spray Test For red rust 240hrs & for white rust 120hrs
Vibration Resistance Vibration level 4.5 to 5.0G
EMC NA
Industry Automotive
Data Sheet
